Calpeda GMC submersible drainage pumps with single channel impeller in cast iron 3x400V

previous next
Calpeda GMC submersible drainage pumps with single channel impeller in cast iron 3x400V

Submersible Pumps FLOW 1 / 3000 mc/h HEAD 3 / 66 m POWER 1.4 / 84.1 kW

See more

Technical Specifications

Maximum flow [l/min]
800
Maximum head [m]
17.30
Input voltage [V]
3x400
Power output - P2 [kW]
1.50

Show all Tech Specs

on demand check availability

1,165.84 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Wastewater pumps
Product No.:
MAS000251

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda GMC 50 AE 400V 1,5kW submersible drainage pump without float switch, 10m cable

Product No.: ZB00025443 Sale group: CECP EAN: 8030485011675 Manuf. No.: 70T20140000

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,165.84 €

Check availability

Maximum flow [l/min]
800
Maximum head [m]
17.30
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
3.80
Maximum liquid temperature [°C]
35
Maximum particle size [mm]
45
Protection [IP]
X8
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Construction

A series of submersible pumps with high efficiency hydraulics designed to move slurry, sewage and industrial process fluids.
The range covers a wide field of use with head up to 75 m And flows up to 2300 m3/h, with a maximum solid passage up to 140 mm keeping the risk of blockage to a minimum.
Dimensionally designed for heavy demand, even on critical applications.
Explosion proof version on request.

Instructions

Technical Specifications

Maximum flow [l/min]
800
Maximum head [m]
17.30
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
3.80
Maximum liquid temperature [°C]
35
Maximum particle size [mm]
45
Protection [IP]
X8
Automatic thermal protection
YES
Dry run protection
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
