Calpeda MXHM 402E 230V 0,45kW

Horizontal Multi-Stage Close Coupled Pumps in stainless steel

See more

Technical Specifications

Maximum flow [l/min]
133
Maximum head [m]
23
Input voltage [V]
230
Power output - P2 [kW]
0.45

Show all Tech Specs

on demand check availability

346.35 € VAT included

On demand

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Horizontal surface pumps
Product No.:
ZB00001607
Sale group:
CECP
EAN:
8030485008576
Manuf. No.:
62311021000

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda MXHM 402E 230V 0,45kW

Product No.: ZB00001607 Sale group: CECP EAN: 8030485008576 Manuf. No.: 62311021000

on demand
check availability
Product availability
  • central warehouse 0 pcs

346.35 €

Check availability

Maximum flow [l/min]
133
Maximum head [m]
23
Input voltage [V]
230
Power output - P2 [kW]
0.45
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
3
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage
You are viewing this variant

Calpeda MXHM 403/A 230V 0,55kW IE2

Product No.: ZB00070326 Sale group: CECP Manuf. No.: 62341031000

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

459.50 €

Maximum flow [l/min]
133
Maximum head [m]
33
Input voltage [V]
230
Power output - P2 [kW]
0.55
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
4.20
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXHM 404/A 230V 0,75kW IE2

Product No.: ZB00070317 Sale group: CECP Manuf. No.: 62341041000

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

471.39 €

Maximum flow [l/min]
133
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
5.40
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXHM 405 230V 1,1kW IE2

Product No.: ZB00070322 Sale group: CECP Manuf. No.: 62331051000

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

650.85 €

Maximum flow [l/min]
133
Maximum head [m]
57
Input voltage [V]
230
Power output - P2 [kW]
1.10
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
7.40
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXHM 406 230V 1,5kW

Product No.: ZB00040315 Sale group: CECP EAN: 8030485288145 Manuf. No.: 62321061000

on demand
check availability
Product availability
  • central warehouse 0 pcs

762.40 €

Check availability

Maximum flow [l/min]
133
Maximum head [m]
69
Input voltage [V]
230
Power output - P2 [kW]
1.50
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
9.20
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage

Product description

Construction

Horizontal multi-stage close coupled pumps in chrome-nickel stainless steel.
Compact and robust construction, without protruding flange and with single-piece lantern bracket and base.
Single-piece barrel casing, with front suction port above pumps axis and radial delivery at top.
Filling and draining plugs on the middle of the pump, accessible from any side (like the terminal box).

Applications

- For water supply.
- For clean liquids, without abrasives, which are non-aggressive for stainless steel (with suitable seal materials, on request).
- Universal pump, for civil and industrial applications, for garden use and irrigation.



Instructions

Technical Specifications

Maximum flow [l/min]
133
Maximum head [m]
23
Input voltage [V]
230
Power output - P2 [kW]
0.45
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
3
Maximum liquid temperature [°C]
110
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
multi-stage
