Calpeda MXV 65-3204 400/690V 7,5kW

Vertical Multi-Stage In-Line Pumps See more

Technical Specifications

Maximum flow [l/min]
733
Maximum head [m]
75
Input voltage [V]
3x400
Power output - P2 [kW]
7.50

Show all Tech Specs

on demand check availability

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email marketing@pumpa.cz

3,187.92 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Vertical surface pumps
Product No.:
ZB00001617
Sale group:
CECP
EAN:
8030485696049
Manuf. No.:
50440421B00

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda MXV 65-3202 400/690V 4,0kW

Product No.: ZB00001613 Sale group: CECP EAN: 8030485895084 Manuf. No.: 50440221L00

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,176.03 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
37
Input voltage [V]
3x400
Power output - P2 [kW]
4
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
9.60
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3203 400/690V 5,5kW

Product No.: ZB00001615 Sale group: CECP EAN: 8030485693635 Manuf. No.: 50440321B00

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,838.99 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
55.50
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
10.90
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3204 400/690V 7,5kW

Product No.: ZB00001617 Sale group: CECP EAN: 8030485696049 Manuf. No.: 50440421B00

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,187.92 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
75
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
14.30
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage
You are viewing this variant

Calpeda MXV 65-3205/D 400/690V 11,0kW

Product No.: ZB00014134 Sale group: CECP EAN: 8030485853367 Manuf. No.: 50440521L00

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,971.28 €

Not sellable online

Maximum flow [l/min]
733
Input voltage [V]
3x400
Power output - P2 [kW]
11
Suction port ["]
DN65
Delivery port ["]
DN65
Drinking water certificate
YES
Maximum current [A]
21.50
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3206 400/690V 11,0kW

Product No.: ZB00014136 Sale group: CECP EAN: 8030485853374 Manuf. No.: 50440621L00

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,374.89 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
122
Input voltage [V]
3x400
Power output - P2 [kW]
11
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
21.50
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3207 400/690V 15,0kW

Product No.: ZB00014139 Sale group: CECP EAN: 8030485847465 Manuf. No.: 50440721L00

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,899.29 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
131
Input voltage [V]
3x400
Power output - P2 [kW]
15
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
27.30
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3208 400/690V 15,0kW

Product No.: ZB00014140 Sale group: CECP EAN: 8030485841333 Manuf. No.: 50440821L00

on demand
check availability
Product availability
  • central warehouse 0 pcs

5,129.31 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
150
Input voltage [V]
3x400
Power output - P2 [kW]
15
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
27,30
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3209 400/690V 18,5kW

Product No.: ZB00025639 Sale group: CECP EAN: 8030485426394 Manuf. No.: 50440921S00

on demand
check availability
Product availability
  • central warehouse 0 pcs

5,557.02 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
168
Input voltage [V]
3x400
Power output - P2 [kW]
18.50
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
34
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Calpeda MXV 65-3210 400/690V 18,5kW

Product No.: ZB00014141 Sale group: CECP EAN: 8030485226871 Manuf. No.: 50441021S00

on demand
check availability
Product availability
  • central warehouse 0 pcs

5,962.46 €

Not sellable online

Maximum flow [l/min]
733
Maximum head [m]
187
Input voltage [V]
3x400
Power output - P2 [kW]
18.50
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
34
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage

Product description

Construction


Vertical multi-stage pumps with suction and delivery connections of the same diameter and arranged along the same axis (in-line).
Corrosion-resistant bearing sleeves lubricated by the pumped liquid.
A pump with thrust bearing and sleeve coupling for use of any standard motor with IM V1 construction.

Applications


- For water supply systems.
- For clean non-explosive liquids, without solid, filamentary or abrasive matter (with adaptation of sealing materials on request).
- A universal pump for civil and industrial use, for pressure-boosting systems, fire-extinguishing systems, high-pressure washing plants, irrigation, agricultural uses and sport installations.

Instructions

Technical Specifications

Maximum flow [l/min]
733
Maximum head [m]
75
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum suction lift [m]
8
Drinking water certificate
YES
Maximum current [A]
14.30
Maximum liquid temperature [°C]
110
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
vertical
Impeller material
stainless steel
Construction
multi-stage
