A product replacement is available
Franklin Electric 4 VS3/20-Y-R14-M4-50DP hydraulic part without motor (1,5kW)
Franklin Electric 4 VS 3/20 hydraulic part without motor (1,5kW)
Technical Specifications
- Maximum flow [l/min]
- 70
- Maximum head [m]
- 140
- Input voltage [V]
- without motor
- Power output - P2 [kW]
- 1.50
- Brand:
- Franklin Electric
- Category:
- Submersible borehole pumps
- Product No.:
- ZB00067174
- Sale group:
- CEFR
- Manuf. No.:
- 602032001050063
Product description
APPLICATIONS
- Municipal water works, fountains and waste water
- Water distribution and pressure boosting
- Irrigation and sprinkler systems, water treatment plants, filtration and reverse osmosis
- Industrial cooling and processing
- Mining industry, drainage and dewatering
- Fire-fighting equipment
- Water supply to and from tanks, reservoir and wells
- Lifting and distribution of a wide range of liquids
- Autoclave and cistern charge and discharge
- Turf and landscape
- Greenhouses and nurseries
- Residential and farm wells and drainage
- Food industry
- General industry
FEATURES
- Compact, reliable and suited to operate in horizontal position.
- Built-in check valve to protect the pump against water hammer risk.
- Floating impellers to grant a better performance and longer life for the pump against abrasion.
- The hydraulic design is such to enhance the overall efficiency thus reducing energy consumption and making the pumping systems more cost effective.
Technical Specifications
- Maximum flow [l/min]
- 70
- Maximum head [m]
- 140
- Input voltage [V]
- without motor
- Power output - P2 [kW]
- 1.50
- Rated flow [l/m]
- 50
- Rated head [m]
- 87
- Delivery port ["]
- 5/4
- Pump diameter ["]
- 4
- Drinking water certificate
- YES
- Float switch
- NO
- Maximum liquid temperature [°C]
- 40
- Maximum particle size [mm]
- 2
- Maximum borehole diameter [mm]
- 95
- Impeller material
- noryl
- Construction
- centrifugal
