PUMPA blue line 4STM submersible pump

previous next
PUMPA blue line 4STM submersible pump

Submersible 4" pump for dug and drilled wells. Designed for clean water pumping. Suitable for household water supply and garden irrigation. Pump casing, motor, pump shaft - stainless steel. Max. immersion depth 40 m. See more

Technical Specifications

Maximum flow [l/min]
75
Maximum head [m]
74 - 128
Input voltage [V]
230
Power output - P2 [kW]
0.55 - 1.10

Show all Tech Specs

in stock >100 pcs

from 203.33 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001047

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line 4STM 211 0,55kW 230V, submersible pump, cable 30m, switch box

Product No.: ZB00061317 Sale group: CEBL EAN: 8596455020851

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

203.33 €

Maximum flow [l/min]
75
Maximum head [m]
74
Input voltage [V]
230
Power output - P2 [kW]
0.55
Rated flow [l/m]
48
Rated head [m]
48
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.80
Maximum liquid temperature [°C]
35
Cable length [m]
30
Maximum particle size [mm]
0.20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA blue line 4STM 214 0,75kW 230V, submersible pump, cable 40m, switch box

Product No.: ZB00061466 Sale group: CEBL EAN: 8596455020868

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

244.78 €

Maximum flow [l/min]
75
Maximum head [m]
95
Input voltage [V]
230
Power output - P2 [kW]
0.75
Rated flow [l/m]
48
Rated head [m]
62
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6.30
Maximum liquid temperature [°C]
35
Cable length [m]
40
Maximum particle size [mm]
0.20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA blue line 4STM 219 1,1kW 230V, submersible pump, cable 50m, switch box

Product No.: ZB00061471 Sale group: CEBL EAN: 8596455020875

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

285.92 €

Maximum flow [l/min]
75
Maximum head [m]
128
Input voltage [V]
230
Power output - P2 [kW]
1.10
Rated flow [l/m]
48
Rated head [m]
83
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
8.60
Maximum liquid temperature [°C]
35
Cable length [m]
50
Maximum particle size [mm]
0.20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Product description

Application

  • Pumping clean water from dug and drilled wells (with cooling jacket)
  • Irrigation, household water supply
  • The pump can be used both alone or with an expansion vessel as a domestic pressure booster pump

Instructions

Technical Specifications

Maximum flow [l/min]
75
Maximum head [m]
74 - 128
Input voltage [V]
230
Power output - P2 [kW]
0.55 - 1.10
Rated flow [l/m]
48
Rated head [m]
48 - 83
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
40
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.80 - 8.60
Maximum liquid temperature [°C]
35
Cable length [m]
30 - 50
Maximum particle size [mm]
0.20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
