PUMPA blue line PSM4TM 4" motor 3x230V

previous next
PUMPA blue line PSM4TM 4" motor 3x230V

Pumpa submersible motors are specially designed for underwater operation and ensure reliable operation in wells and boreholes with a diameter greater than 130 mm. See more

Technical Specifications

Power output - P2 [kW]
0.55 - 1.50
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO

Show all Tech Specs

in stock >100 pcs

from 174.24 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible motors
Product No.:
MAS001591

Product variants

  • Technical Specifications
  • Product No.
  • Power output - P2 [kW]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PSM4TM 0.55kW 4" motor 3x230V 50Hz

Product No.: ZB00070778 Sale group: ELPU EAN: 8596455040149

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

174.24 €

Power output - P2 [kW]
0.55
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO
Maximum current [A]
3.60
Maximum liquid temperature [°C]
35
Cable length [m]
1
Protection [IP]
68
Automatic thermal protection
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Construction
rewindable

PUMP blue line PSM4TM 0.75kW 4" motor 3x230V 50Hz

Product No.: ZB00070779 Sale group: ELPU EAN: 8596455040156

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

185.13 €

Power output - P2 [kW]
0.75
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO
Maximum current [A]
4.70
Maximum liquid temperature [°C]
35
Cable length [m]
1
Protection [IP]
68
Automatic thermal protection
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Construction
rewindable

PUMP blue line PSM4TM 1.1 kW 4" motor 3x230V 50Hz

Product No.: ZB00070780 Sale group: ELPU EAN: 8596455040163

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

196.02 €

Power output - P2 [kW]
1.10
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO
Maximum current [A]
5.80
Maximum liquid temperature [°C]
35
Cable length [m]
1
Protection [IP]
68
Automatic thermal protection
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Construction
rewindable

PUMPA blue line PSM4TM 1.5 kW 4" motor 3x230V 50Hz

Product No.: ZB00070781 Sale group: ELPU EAN: 8596455040170

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

206.91 €

Power output - P2 [kW]
1.50
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO
Maximum current [A]
7.30
Maximum liquid temperature [°C]
35
Cable length [m]
1
Protection [IP]
68
Automatic thermal protection
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Construction
rewindable

Product description

Pumpa submersible motors are specially designed for underwater operation and ensure reliable operation in wells and boreholes with a diameter greater than 130 mm.

Applications

For pumps designed for:

  • Clean water supply
  • Dewatering, pressure multiplication, irrigation systems
  • For supplying households, cottages or gardens


Distinctive design features

  • Reversible, oil-filled motors allow maintenance-free operation
  • PSM4TM motors can be submerged to depths of up to 40-60 metres
  • Mounting specifications of motors to NEMA standard

Technical Specifications

Power output - P2 [kW]
0.55 - 1.50
Pump diameter ["]
4
Maximum immersion depth [m]
60
Drinking water certificate
NO
Maximum current [A]
3.60 - 7.30
Maximum liquid temperature [°C]
35
Cable length [m]
1
Protection [IP]
68
Automatic thermal protection
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Construction
rewindable
