PUMPA inox line CDPM centrifugal pumps with one impeller 230V

Centrifugal pumps with one impeller PUMPA INOX LINE CDPM. The hydraulic part of the pumps is made entirely of high-quality AISI304 stainless steel. The pumps are suitable for industrial use. They are used for water supply, pressure boosting, irrigation, food processing, circulation and cooling systems.   See more

Technical Specifications

Maximum flow [l/min]
110 - 200
Maximum head [m]
20 - 38
Input voltage [V]
230
Power output - P2 [kW]
0.55 - 2.20

Show all Tech Specs

in stock >10 pcs

from 320.55 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Horizontal surface pumps
Product No.:
MAS001713

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Power input - P1 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Maximum pressure [bar]
  • Protection [IP]
  • Output voltage [V]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA INOX LINE CDPM70/037 0.55 kW 230 V/50 Hz surface pump

Product No.: ZB00075614 Sale group: CESTP EAN: 8596455044499

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

320.55 €

Maximum flow [l/min]
110
Maximum head [m]
20
Input voltage [V]
230
Power output - P2 [kW]
0.55
Suction port ["]
5/4
Power input - P1 [kW]
0.75
Rated flow [l/m]
70
Rated head [m]
14
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE CDPM70/055 0.75kW 230V/50Hz surface pump

Product No.: ZB00075616 Sale group: CESTP EAN: 8596455044529

in stock
6 pcs
Product availability
  • central warehouse 6 pcs

335.85 €

Maximum flow [l/min]
110
Maximum head [m]
28
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
5/4
Power input - P1 [kW]
1.04
Rated flow [l/m]
70
Rated head [m]
19
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
4.60
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE CDPM90/075 1kW 230V/50Hz surface pump

Product No.: ZB00075618 Sale group: CESTP EAN: 8596455044543

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

387.68 €

Maximum flow [l/min]
150
Maximum head [m]
30
Input voltage [V]
230
Power output - P2 [kW]
1
Suction port ["]
5/4
Power input - P1 [kW]
1.38
Rated flow [l/m]
90
Rated head [m]
22
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
5.80
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE CDPM120/055 0.75kW 230V/50Hz surface pump

Product No.: ZB00075620 Sale group: CESTP EAN: 8596455044567

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

337.30 €

Maximum flow [l/min]
160
Maximum head [m]
22
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
5/4
Power input - P1 [kW]
1.04
Rated flow [l/m]
120
Rated head [m]
16
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
4.60
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE CDPM120/090 PUMP 1.1 kW 230 V/50 Hz surface pump

Product No.: ZB00075622 Sale group: CESTP EAN: 8596455044581

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

438.89 €

Maximum flow [l/min]
180
Maximum head [m]
31
Input voltage [V]
230
Power output - P2 [kW]
1.10
Suction port ["]
5/4
Power input - P1 [kW]
1.50
Rated flow [l/m]
120
Rated head [m]
23
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
6.30
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

PUMPA INOX LINE CDPM120/150 2.2kW 230V/50Hz surface pump

Product No.: ZB00075624 Sale group: CESTP EAN: 8596455044604

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

496.78 €

Maximum flow [l/min]
200
Maximum head [m]
38
Input voltage [V]
230
Power output - P2 [kW]
2.20
Suction port ["]
5/4
Power input - P1 [kW]
2.25
Rated flow [l/m]
120
Rated head [m]
28
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
10.30
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal

Product description

Centrifugal pumps with one impeller PUMPA INOX LINE CDPM. The hydraulic part of the pumps is made entirely of high-quality AISI304 stainless steel. The pumps are suitable for industrial use. They are used for water supply, pressure boosting, irrigation, food processing, circulation and cooling systems.

Main advantages

  • High efficiency – the pump is equipped with a single impeller, which ensures high discharge and high efficiency
  • Corrosion protection – parts that come into contact with liquids are made of AISI 304 stainless steel
  • Motor: single-phase 1x230V 50HZ
  • Safe and reliable operation – the pump is equipped with a mechanical seal
  • Wide range of applications – industrial and domestic applications

Use

  • Water transport for industrial and domestic applications
  • Pressure boosting in systems
  • Irrigation
  • Cooling and circulation systems
  • Food applications
  • Water treatment
  • Car washes

Instructions

Technical Specifications

Maximum flow [l/min]
110 - 200
Maximum head [m]
20 - 38
Input voltage [V]
230
Power output - P2 [kW]
0.55 - 2.20
Suction port ["]
5/4
Power input - P1 [kW]
0.75 - 2.25
Rated flow [l/m]
70 - 120
Rated head [m]
14 - 28
Delivery port ["]
5/4
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
3.50 - 10.30
Maximum liquid temperature [°C]
70
Maximum pressure [bar]
10 - 10
Protection [IP]
55
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Pump design
horizontal
Impeller material
stainless steel
Construction
centrifugal
