PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor
PUMPA inox line SPP-05 4-inch submersible pump 230V with Coverco motor

PUMPA inox line SPP 4" submersible pumps are developed according to the latest technology. They are made of corrosion and abrasion resistant stainless steel. The SPP series pumps meet the highest standards of energy efficiency and are suitable for the most demanding applications with their high performance, robust design and long service life. See more

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
50 - 238
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 1.10

Show all Tech Specs

in stock 3 pcs

from 560.86 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001023

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Check valve
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line SPP-0509 4" 0,37kW 230V 20mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060075 Sale group: CEST EAN: 8596455016373

in stock in 5 working days
4 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 4 pcs

560.86 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
50
Input voltage [V]
230
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
36
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0514 4" 0,37kW 230V 20mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060077 Sale group: CEST EAN: 8596455016397

in stock
1 pcs
Product availability
  • central warehouse 1 pcs
  • available within 5 working days 6 pcs

637.86 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
78
Input voltage [V]
230
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
56
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0518 4" 0,55kW 230V 25mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060079 Sale group: CEST EAN: 8596455016410

in stock
1 pcs
Product availability
  • central warehouse 1 pcs
  • available within 5 working days 7 pcs

715.35 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
102
Input voltage [V]
230
Power output - P2 [kW]
0.55
Rated flow [l/m]
15
Rated head [m]
72
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.80
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0521 4" 0,55kW 230V 25mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060082 Sale group: CEST EAN: 8596455016441

in stock in 5 working days
6 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 6 pcs

762.01 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
118
Input voltage [V]
230
Power output - P2 [kW]
0.55
Rated flow [l/m]
15
Rated head [m]
81
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.80
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0528 4" 0,75kW 230V 35mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060085 Sale group: CEST EAN: 8596455016472

in stock
1 pcs
Product availability
  • central warehouse 1 pcs
  • available within 5 working days 6 pcs

887.75 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
158
Input voltage [V]
230
Power output - P2 [kW]
0.75
Rated flow [l/m]
15
Rated head [m]
111
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6.20
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0536 4" 1,1kW 230V 40mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060088 Sale group: CEST EAN: 8596455016502

in stock in 5 working days
3 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 3 pcs

1,114.70 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
205
Input voltage [V]
230
Power output - P2 [kW]
1.10
Rated flow [l/m]
15
Rated head [m]
134
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
8.30
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-0542 4" 1,1kW 230V 40mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060091 Sale group: CEST EAN: 8596455016533

in stock in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

1,235.36 €

Not sellable online

Maximum flow [l/min]
25
Maximum head [m]
238
Input voltage [V]
230
Power output - P2 [kW]
1.10
Rated flow [l/m]
15
Rated head [m]
167
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
8.30
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

Product description

Application

  • Drinking water supply of residential buildings from deep drilled wells
  • Utility and industrial water supply
  • Irrigation and other agricultural applications
  • Fire protection systems
  • Pressure amplification in high-rise buildings
  • Other applications

Characteristics

  • Stainless steel construction developed and manufactured to provide many years of fault-free operation
  • All metal parts are made of grade 304 stainless steel, except the shaft made of grade 431 stainless steel
  • Heavy-duty stainless steel discharge head with built-in check valve for long life and easy installation
  • Engine mounting specifications according to NEMA standard
  • High quality shaft bearings ensuring low friction and high wear resistance
  • Stainless steel impellers and diffusers for heavy loads providing optimum performance
  • Stainless steel strainer to prevent the ingress of sand and other impurities

Instructions

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
50 - 238
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 1.10
Rated flow [l/m]
15
Rated head [m]
36 - 167
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50 - 8.30
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal
