PUMPA inox line STP-05 4-inch submersible pump 230V

PUMPA inox line STP 4" submersible pumps are developed according to the latest technology. The STP series pumps meet the highest standards of energy efficiency and are suitable for the most demanding applications with their high performance, robust design and long service life. See more

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
67 - 173
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 0.75

Show all Tech Specs

in stock 1 pcs

from 456.64 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001015

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line STP-0510 4" 0,37kW 230V 20mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060192 Sale group: CEST EAN: 8596455017547

available in 5 working days
3 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 3 pcs

456.64 €

Maximum flow [l/min]
25
Maximum head [m]
67
Input voltage [V]
230
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
46
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA inox line STP-0513 4" 0,37kW 230V 20mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060197 Sale group: CEST EAN: 8596455017592

in stock
1 pcs
Product availability
  • central warehouse 1 pcs
  • available within 5 working days >10 pcs

475.68 €

Maximum flow [l/min]
25
Maximum head [m]
86
Input voltage [V]
230
Power output - P2 [kW]
0.37
Rated flow [l/m]
15
Rated head [m]
56
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA inox line STP-0519 4" 0,55kW 230V 25mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060201 Sale group: CEST EAN: 8596455017639

available in 5 working days
>10 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days >10 pcs

521.11 €

Maximum flow [l/min]
25
Maximum head [m]
126
Input voltage [V]
230
Power output - P2 [kW]
0.55
Rated flow [l/m]
15
Rated head [m]
86
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
4.60
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA inox line STP-0526 4" 0,75kW 230V 36mF submersible pump with Coverco motor, cable 1,7m

Product No.: ZB00060204 Sale group: CEST EAN: 8596455017660

available in 5 working days
>10 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days >10 pcs

614.24 €

Maximum flow [l/min]
25
Maximum head [m]
173
Input voltage [V]
230
Power output - P2 [kW]
0.75
Rated flow [l/m]
15
Rated head [m]
117
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6.20
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Product description

Application

  • Water supply
  • Irrigation
  • Pressure boost

Features

  • The delivery and suction casing of the pump are precision-machined parts made of grade 304 cast stainless steel, providing superior strength and durability. The suction casing is NEMA compliant.
  • Floating impellers are made with the addition of NorylR material for perfect sand processing.
  • The pump jacket is made of 304 stainless steel to ensure maximum abrasion resistance.
  • 304 stainless steel shaft coupling allows easy alignment with the motor shaft.
  • The strainer is made of embossed stainless steel 304, which gives it the necessary strength.
  • 304 stainless steel check valve installed in the head prevents the backflow of water and minimalize the water shock affecting
    the pumps.
  • Hexagonal 304 steel rod pump shaft provides high corrosion resistance.
  • 1.5 mm thick polished 304 stainless steel pump casing jacket ensures optimal abrasion resistance.
  • Polyacetal bearing provides high wear and abrasion resistance.

Instructions

Technical Specifications

Maximum flow [l/min]
25
Maximum head [m]
67 - 173
Input voltage [V]
230
Power output - P2 [kW]
0.37 - 0.75
Rated flow [l/m]
15
Rated head [m]
46 - 117
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
250
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.50 - 6.20
Maximum liquid temperature [°C]
30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO, YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
external
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
