PUMPA inox line STP-4017 4" hydraulic part without motor (3kW)

PUMPA inox line STP 4" submersible pumps are developed according to the latest technology. The STP series pumps meet the highest standards of energy efficiency and are suitable for the most demanding applications with their high performance, robust design and long service life. See more

Technical Specifications

Maximum flow [l/min]
200
Maximum head [m]
108
Input voltage [V]
without motor
Power output - P2 [kW]
3

Show all Tech Specs

in stock 5 pcs

282.95 € VAT included

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
ZB00059835
Sale group:
CEST
EAN:
8596455015918

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Drinking water certificate
  • Float switch
  • Maximum liquid temperature [°C]
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line STP-4008 4" hydraulic part without motor (1,5kW)

Product No.: ZB00059833 Sale group: CEST EAN: 8596455015895

on demand
check availability
Product availability
  • central warehouse 0 pcs

178.69 €

Check availability

Maximum flow [l/min]
200
Maximum head [m]
52
Input voltage [V]
without motor
Power output - P2 [kW]
1,50
Rated flow [l/m]
140
Rated head [m]
37
Delivery port ["]
2
Pump diameter ["]
4
Drinking water certificate
NO
Float switch
NO
Maximum liquid temperature [°C]
35
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA inox line STP-4013 4" hydraulic part without motor (2,2kW)

Product No.: ZB00059834 Sale group: CEST EAN: 8596455015901

in stock
6 pcs
Product availability
  • central warehouse 6 pcs

243.26 €

Maximum flow [l/min]
200
Maximum head [m]
82
Input voltage [V]
without motor
Power output - P2 [kW]
2,20
Rated flow [l/m]
140
Rated head [m]
59
Delivery port ["]
2
Pump diameter ["]
4
Drinking water certificate
NO
Float switch
NO
Maximum liquid temperature [°C]
35
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

PUMPA inox line STP-4017 4" hydraulic part without motor (3kW)

Product No.: ZB00059835 Sale group: CEST EAN: 8596455015918

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

282.95 €

Maximum flow [l/min]
200
Maximum head [m]
108
Input voltage [V]
without motor
Power output - P2 [kW]
3
Rated flow [l/m]
140
Rated head [m]
79
Delivery port ["]
2
Pump diameter ["]
4
Drinking water certificate
NO
Float switch
NO
Maximum liquid temperature [°C]
35
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
You are viewing this variant

Product description

Application

  • Water supply
  • Irrigation
  • Pressure boost

Features

  • The delivery and suction casing of the pump are precision-machined parts made of grade 304 cast stainless steel, providing superior strength and durability. The suction casing is NEMA compliant.
  • Floating impellers are made with the addition of NorylR material for perfect sand processing.
  • The pump jacket is made of 304 stainless steel to ensure maximum abrasion resistance.
  • 304 stainless steel shaft coupling allows easy alignment with the motor shaft.
  • The strainer is made of embossed stainless steel 304, which gives it the necessary strength.
  • 304 stainless steel check valve installed in the head prevents the backflow of water and minimalize the water shock affecting
    the pumps.
  • Hexagonal 304 steel rod pump shaft provides high corrosion resistance.
  • 1.5 mm thick polished 304 stainless steel pump casing jacket ensures optimal abrasion resistance.
  • Polyacetal bearing provides high wear and abrasion resistance.

Technical Specifications

Maximum flow [l/min]
200
Maximum head [m]
108
Input voltage [V]
without motor
Power output - P2 [kW]
3
Rated flow [l/m]
140
Rated head [m]
79
Delivery port ["]
2
Pump diameter ["]
4
Drinking water certificate
NO
Float switch
NO
Maximum liquid temperature [°C]
35
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
