PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m

PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m

Vortex Slurry Pump with Swirling Impeller. Suitable for pumping wastewater containing coarse impurities up to 100 mm in size. See more

Technical Specifications

Maximum flow [l/min]
1,583
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
5.50

Show all Tech Specs

in stock 5 pcs

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email [email protected]

1,797.54 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
ZB00061124
Sale group:
CEBKP
EAN:
8596455020363

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Minimum level height [mm]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA black line 80BLV41.5-P80 WD 400V 1,5kW,wastewater pump, Vortex impeller, throughput 80mm, cable 15m with leakage sensor

Product No.: ZB00074741 Sale group: CEBKP EAN: 8596455043423

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,131.86 €

Not sellable online

Maximum flow [l/min]
1,100
Maximum head [m]
10
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Rated flow [l/m]
600
Rated head [m]
5.50
Delivery port ["]
DN80
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
3.70
Maximum liquid temperature [°C]
40
Minimum level height [mm]
230
Cable length [m]
15
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLV42.2-P80 WD 400V 2,2kW, wastewater pump, Vortex impeller, throughput 80mm, cable 15m with leakage sensor

Product No.: ZB00074742 Sale group: CEBKP EAN: 8596455043430

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

1,190.41 €

Not sellable online

Maximum flow [l/min]
1,250
Maximum head [m]
10
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Rated flow [l/m]
600
Rated head [m]
7
Delivery port ["]
DN80
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
5.30
Maximum liquid temperature [°C]
40
Minimum level height [mm]
230
Cable length [m]
15
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLV43.7-P80 WD 400V 3,7kW, wastewater pump, Vortex impeller, throughput 80mm, cable 15m with leakage sensor

Product No.: ZB00074743 Sale group: CEBKP EAN: 8596455043447

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

1,414.83 €

Not sellable online

Maximum flow [l/min]
1,500
Maximum head [m]
13
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Rated flow [l/m]
600
Rated head [m]
10
Delivery port ["]
DN80
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
8.30
Maximum liquid temperature [°C]
40
Minimum level height [mm]
230
Cable length [m]
15
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m

Product No.: ZB00061124 Sale group: CEBKP EAN: 8596455020363

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

1,797.54 €

Not sellable online

Maximum flow [l/min]
1,583
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
8
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
You are viewing this variant

PUMPA black line 80BLV47.5 400V 7,5kW, sewage pump, Vortex impeller, maximum particle size 80mm, cable 8m

Product No.: ZB00061126 Sale group: CEBKP EAN: 8596455020349

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

2,169.44 €

Not sellable online

Maximum flow [l/min]
1,833
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15.70
Cable length [m]
8
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLV43.7-P100 WD 400V 3,7kW, wastewater pump, Vortex impeller, throughput 100mm, cable 15m with leakage sensor

Product No.: ZB00074744 Sale group: CEBKP EAN: 8596455043454

in stock
9 pcs
Product availability
  • central warehouse 9 pcs

1,476.63 €

Not sellable online

Maximum flow [l/min]
1,916.70
Maximum head [m]
10
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Rated flow [l/m]
1,000
Rated head [m]
8
Delivery port ["]
DN100
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
8.30
Maximum liquid temperature [°C]
40
Minimum level height [mm]
280
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLV45.5 400V 5,5kW, sewage pump, Vortex impeller, maximum particle size 56mm, cable 15m

Product No.: ZB00065210 Sale group: CEBKP EAN: 8596455036234

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

1,822.43 €

Not sellable online

Maximum flow [l/min]
2,250
Maximum head [m]
14
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLV45.5-P100 WD 400V 5,5kW, wastewater pump, Vortex impeller, throughput 100 mm, cable 15m with leakage sensor

Product No.: ZB00074747 Sale group: CEBKP EAN: 8596455043485

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,081.59 €

Not sellable online

Maximum flow [l/min]
2,250
Maximum head [m]
14
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMP black line 100BLV47.5-P100 WD 400V 7.5kW, wastewater pump, Vortex impeller, throughput 100mm, cable 15m with leakage sensor

Product No.: ZB00065212 Sale group: CEBKP EAN: 8596455036258

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

2,306.01 €

Not sellable online

Maximum flow [l/min]
2,750
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15.70
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMP black line 100BLV411-P100 WD 400V 11kW, wastewater pump, Vortex impeller, maximum particle size 100mm, cable 15m with leakage sensor

Product No.: ZB00065213 Sale group: CEBKP EAN: 8596455036272

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

2,423.95 €

Not sellable online

Maximum flow [l/min]
3,167
Maximum head [m]
18
Input voltage [V]
3x400
Power output - P2 [kW]
11
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
22
Cable length [m]
15
Maximum particle size [mm]
100
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Description

Vortex Slurry Pump with Swirling Impeller. Suitable for pumping wastewater containing coarse impurities up to 100 mm in size.

Use

  • wastewater pumping
  • gas station
  • wastewater treatment plants
  • drainage water pumping
  • rainwater pumping
  • industrial applications

Instructions

Technical Specifications

Maximum flow [l/min]
1,583
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
8
Maximum particle size [mm]
80
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product Safety Information

Company responsible for product safety:
PUMPA,a.s.
U Svitavy 54/1, Brno 618 00, CZ
e-mail: [email protected]

Accessories

previous next
